Visitors to Xaar’s Open Day & FuturePrint Tech Conference in Cambridge United Kingdom were the first to see the results of a research study into jetting high viscosity water-based inks, performed by Dr Chris Phillips and Professor Davide Deganello at the Welsh Centre for Printing and Coating, Swansea University.
During the Open Day, Dr Chris Phillips provided independent evidence of the results of jetting higher viscosity inks when compared to ‘conventional’ viscosities on both coated and uncoated substrates. Using the Xaar Aquinox printhead and cyan water-based inks by Nazdar, the research team showed several advantages to printing high viscosity fluids, which is enabled by Xaar’s Ultra High Viscosity Technology. Measured colour densities were seen to be up to 60 percent higher, enabling productivity gains and an enhanced gamut by jetting the higher viscosity ink.
Xaar’s printhead technology capabilities meant that the higher viscosity sample saw the same printing outcome with less ink, offering significant sustainability benefits through both reducing the volume of ink required and the energy needed in drying. Two ink sets were tested, one with a higher pigment loading, and both high and conventional viscosity inks in each ink set had a fixed pigment to binder ratio to enable a fair comparison. This demonstrated that viscosity was the key enabler to the improved colour results rather than the pigment loading. The lower amount of water in the higher viscosity inks meant less absorption into the substrate, delivering the enhanced colour impact without the need for more pigment. In addition, the trials on the non-coated board showed that by using Ultra High Viscosity to enable a higher pigment load than is usually possible, a far higher colour density is achieved. This opens up the possibility of removing the primer when printing onto cardboard, delivering sustainability and process simplification benefits.
